10KV 3 Cores Heat Shrinkable Outdoor Termination Manufacturers

The Heat Shrinkable Insulation Tube is a special heat shrinkable casing made of polyolefin material. The outer layer is made of high quality soft crosslinked polyolefin material and the inner layer of hot melt adhesive. The outer layer has the characteristics of insulation, corrosion resistance and wear resistance, and the inner layer has the advantages of low melting point, waterproof sealing and high adhesion.

Porcelain Sheathed Cable Termination is a important part of 110kV products. The main varieties of 110kV and above XLPE insulated cable termination are: Outdoor termination, GIS termination (installed in fully enclosed combined appliances) and transformer termination (installed in transformer oil tanks). Prefabricated Rubber Stress Cone Termination and Prefabricated Intermediate Joint are main type of high voltage crosslinked cable accessories used in China. Our 110kV series products meet the requirements of IEC60840 and GB/T11017.3, the product adopts special electric field analysis software to optimize the design, and they are made of high quality materials and advanced production technology, it ensures uniform electric field, stable performance and reliable operation.

The Heat Shrinkable Double-walled Tube is one of the Heat Shrinkable Products series, compared with the traditional cable accessories, the heat-shrinkable cable accessories have the characteristics of small volume, light weight, safety and reliability, and convenient installation. The Double-walled Tube is suitable for electric power, aviation, electronics, communication, automobile and other fields, with insulation, waterproof sealing, corrosion resistance, aging resistance and other characteristics.

The 24kV Cold Shrinkable Single Core Termination Kit for Indoor are anti-pollution, anti-aging, good hydrophobicity, excellent cold resistance and heat resistance, especially suitable for high altitude area, cold area, wet area, salt fog area and heavy pollution area. And installation without open fire, especially suitable for petroleum, chemical, mining and other flammable and explosive places.

10kV and 24kV Straight-through Cable Connector threads into a universal bushing well to provide the same function as an integral load break bushing. Using bushing inserts makes field installation and replacement possible and efficient. Bushing insert and elbow connectors comprise the essential components of all load break connections. It is mainly used as the high-voltage electrical connection for American box, outdoor ring network cabinet. Bushing insert is used with bushing holder that makes it possible to on-site installation and replacement.

The installation of 1kV Cold Shrinkable Two Cores Straight Through Joint kits installation procedures from one end to the other side of the construction, the construction process cannot be changed, the process is very difficult to have a bubble will appear in the cable pipe, therefore the construction quality is higher, the construction of hot shrinkage is different, heat from one end to the other side, it is easy to result in uneven heating, which leads to the generation of air bubbles, seriously affect the construction quality.
